A site layout plan for the fictional Quellmoor Ridge Wind Farm, showing twelve labeled wind turbine locations (WTG-01 to WTG-12) connected by gray access-road lines. The map includes a north arrow, a 500 m scale bar, contour lines, a green hatched area labeled “Skelvane Wood (bat roost),” a note for an environmental permit curtailment group covering WTG-03 to WTG-05, a met mast symbol, an O&M building, a substation labeled 33/132 kV, and a nearby Quellmoor village dwellings inset. Red text states “FICTIONAL - NOT FOR OPERATIONAL USE,” and a dashed red 132 kV line runs to the Skelvane substation from the site area.
