Figure f02
Generated description — written by a model from the figure image; not verified against the source.
A site layout map for the fictional Quellmoor Ridge Wind Farm showing twelve wind turbine locations labeled WTG-01 to WTG-12 connected by gray access tracks. The map includes contour lines, a north arrow, a 500 m scale bar, nearby features such as Skelvane Wood (bat roost), Quellmoor village, a substation, an O&M building, and a 132 kV line, with several red “FICTIONAL - NOT FOR OPERATIONAL USE” notices. An inset at lower left shows the nearest dwellings, and a legend-style title block at lower right identifies the site layout plan and date.
